Sorry for not writing anything interesting this month so far, it’s been a very hectic month.

Today I saw a question on Stack Overflow regarding debugging. The user was trying to let Visual Studio run in debug mode with his application to see when and why it crashes.

That’s not a solution because there are functions in place for these situations in Windows API. More simply put, you can make your software write a Mini Dump upon crash and then you can just open it inside Visual Studio (or whatever debugger you want) and see exactly where it crashed.

The below example is ready to use for any .exe or .dll on Windows:

 1#pragma once
 2
 3#include <Windows.h>
 4#include <Dbghelp.h>
 5#pragma comment (lib, "Dbghelp.lib")
 6
 7// Because... why not ?!
 8namespace MecanikUtils
 9{
10    LPTOP_LEVEL_EXCEPTION_FILTER PreviousExceptionFilter = 0;
11
12    LONG WINAPI DumpExceptionFilter(EXCEPTION_POINTERS* info)
13    {
14        wchar_t DumpPath[MAX_PATH] = { 0 };
15
16        SYSTEMTIME SystemTime;
17        GetLocalTime(&SystemTime);
18
19        WCHAR szExeFileName[100] = { 0 };
20        GetModuleFileNameW(NULL, szExeFileName, 99);
21
22        wsprintfW(DumpPath, L"Crash_%s_%d-%d-%d_%dh%dm%ds.dmp", szExeFileName, SystemTime.wYear, SystemTime.wMonth, SystemTime.wDay, SystemTime.wHour, SystemTime.wMinute, SystemTime.wSecond);
23
24        HANDLE file = CreateFileW(DumpPath, GENERIC_WRITE, FILE_SHARE_WRITE, 0, CREATE_ALWAYS, FILE_ATTRIBUTE_NORMAL, 0);
25
26        if (file != INVALID_HANDLE_VALUE)
27        {
28            MINIDUMP_EXCEPTION_INFORMATION mdei;
29
30            mdei.ThreadId = (DWORD)GetCurrentThreadId();
31
32            mdei.ExceptionPointers = info;
33
34            mdei.ClientPointers = 0;
35
36            if (MiniDumpWriteDump(GetCurrentProcess(), (DWORD)GetCurrentProcessId(), file, (MINIDUMP_TYPE)(MiniDumpScanMemory + MiniDumpWithIndirectlyReferencedMemory), &mdei, 0, 0) != 0)
37            {
38                CloseHandle(file);
39                return EXCEPTION_EXECUTE_HANDLER;
40            }
41        }
42
43        CloseHandle(file);
44
45        return EXCEPTION_CONTINUE_SEARCH;
46    }
47
48    class MiniDump
49    {
50    public:
51
52        /// <summary>
53        /// Add Unhandled Exception Filter
54        /// </summary>
55        inline static void Init()
56        {
57            // Change if required
58            SetErrorMode(SEM_FAILCRITICALERRORS);
59
60            PreviousExceptionFilter = SetUnhandledExceptionFilter(DumpExceptionFilter);
61        }
62
63        /// <summary>
64        /// Remove Unhandled Exception Filter
65        /// </summary>
66        inline static void Clean()
67        {
68            SetUnhandledExceptionFilter(PreviousExceptionFilter);
69        }
70    };
71}

To use it simply call the following at the start + end of your software’s entry point. For example a .dll:

 1#include "MiniDump.hpp"
 2
 3BOOL APIENTRY DllMain(HANDLE hModule, DWORD ul_reason_for_call, LPVOID lpReserved )
 4{
 5   switch ( ul_reason_for_call )
 6   {
 7      case DLL_PROCESS_ATTACHED:
 8      MecanikUtils::MiniDump::Init();
 9      break;
10
11      case DLL_PROCESS_DETACH:
12      MecanikUtils::MiniDump::Clean();
13      break;
14   }
15   return TRUE;
16}

Feel free to make changes to SetErrorMode if you need to.

Note: Keep the original .pdb of the compiled .exe/.dll if you want to open the Mini Dump. Otherwise you won’t have any easy readable information.

Until next time! 😉
